| General |
| Video Transmission Technology |
IP |
| Image Sensor |
1/2.7” CMOS |
| Video Format |
NTSC |
| Video Compression |
H.265/H.264 (Main Stream & Sub Stream) |
| Optical |
| Viewing Angle (H ×V ×D) |
106° × 56° × 125° |
| Lens/Lens type |
2.8mm F2.0 / Fixed |
| Video Output |
| Resolution / Frame Rate |
4K/8MP@15fps, 5MP@30fps, 1080p@30fps, 720p@30fps |
| Effective Pixels |
3840 (H) × 2160 (V) |
| HDR |
Yes |
| Network Port |
RJ45 |
| Audio |
| Microphone / Speaker |
Yes / Yes |
| Siren |
Yes (Siren sound options available) |
| Two-way Talk |
Yes |
| Night Vision |
| IR Night Vision Range |
98.43 ft / 30 m |
| Color Night Vision |
Yes |
| Special Features |
| Smart Motion Detection |
Yes - Person and Vehicle Detection |
| Detection Types |
Vehicle, Person |
| Supports in App Quick Messaging |
Yes |
| Active Deterrence |
Yes - Warning Light + Siren + Pre Recorded Message |
| Smart Security Lighting |
Yes |
| Additional Specifications |
| Camera Housing Material |
Aluminum Alloy |
| SD Card Slot |
Yes* |
| Power Requirements |
PoE (Power over Ethernet Class -802.3af) / 12V DC |
| Power Consumption (max) |
9.6W (DC12V), 11W (POE) |
| Camera Dimensions (W × H) |
5.6 × 4.7” / 142 × 119 mm |
| Camera Weight |
1.51 lbs / 0.68 kg |
| Operating Temperature |
-40 °F to 140 °F / -40 °C to 60 °C |
| Humidity |
≤ 95% RH |
| Environmental Rating |
IP67 (Indoor/Outdoor) |
*A microSD card can be inserted for independent recording. Data can be accessed through the camera using a web browser but will not upload to the NVR or to the cloud for mobile app viewing
